1.2m Diameter Foam Block Vertical Continuous Foam Machine

1.2m Diameter Foam block Vertical Continuous Foam Machine

Application:

1.2m Diameter Foam block Vertical Continuous Foam Machine mainly produce flexible PU Foam, it is controlled by touch screen PLC system, the advantage is high automatic, low waste percentages and easy to operate. And this kind of foam can be used widely in Furniture, Garment, toy, Bra, shoe, mattress and car cushion

Advantage:

1.2m Diameter Foam block Vertical Continuous Foam Machine can make maximum density 45kg/m3, the disadvantage will have more waste of foam during cutting when compared with 1.5m diameter foam block.

Inquiry Now

Chemical groups

PPG, TDI, M.C, Silicon, Water, T9, A33, Color

Basic data

Delivery diameter	1.2m
Delivery height	8.5 m
Lift speed	1-1.8m/min
Foam density	10-45kg/m3
Mixing head power	11kw
Mixing head rotate speed	2800r/min
Total power	45kw
Heat power	15kw
Cooling capacity	8HP
Foam flow capacity	20-55kg/min
Main frame size	380038008500mm

Inquiry Now
